Powerful Drive Energy Saving LiFePO4 Wall-Mounted Home Energy Storage Battery

Weight:	26kg, 44kg, 65kg, 81kg, 125kg
Warranty:	5 Years
Cycle Life:	6000 Cycles

Overview & Basic Info.

Model NO.

Wall Mounted Storage Power Supply

Nominal Capacity

2.56kwh 5.12kwh 7.68kwh 10.24kwh 16.07kwh

Standard Voltage

25.6V/51.2VDC

Voltage Range

21.6V-28.8V/43.2-57.6VDC

Nominal Capacity

100ah, 150ah, 200ah, 314ah

Communication

Can/RS485/RS232/WiFi/Bluetooth

Cell Self-Discharge

<5%/Month

Modules Connection

1-15 in Parallel

Dod

90%

Max Charge & Discharge Current

100A-200A

IP Rating

IP20(IP54)

Installation

Wall

Working Temperature

0~55℃

Storage Temperature

-20~55℃

Humidity

≤80%

Product Dimension

426*378*160 mm - 530*790*240 mm

Package Dimension

475*500*285 mm - 630*900*510 mm

Transport Package

International Standards

Specification

Standard Specifications or Customized

Production Capacity

1000000pieces/Year

Product Description

RELIABLE WALL-MOUNTED HOME BATTERY STORAGE SYSTEM

Upgrade your home energy management with our Wall-Mounted Energy Storage System—a compact, high-performance LFP (Lithium Iron Phosphate) battery solution designed for residential and light commercial use.

Featuring a scalable capacity from 2.56kWh to 16.07kWh, this home battery backup system delivers exceptional reliability with an impressive 6000+ cycle life at 80% DOD.

The space-saving wall-mount design, combined with a built-in intelligent BMS (Battery Management System), ensures maximum safety and effortless installation.

Whether you're seeking solar energy storage, backup power, or off-grid independence, this premium-grade battery system offers the flexibility to connect up to 15 units in parallel, providing a truly customizable energy storage solution for your evolving needs.

Specification

Model	SMP-BU004	SMP-BU005	SMP-BU006
Battery pack specifications
Nominal Voltage	51.2VDC
Voltage Range	43.2~57.6VDC
Nominal Capacity	280Ah	300Ah	320Ah
Rated Energy	14.336kWh	15.36kWh	16.384kWh
Communication Protocol	CAN / RS485 / RS232 / WIFI / Bluetooth
Cell Self-discharge	<5% / month
Supported Parallel Quantity	1~15 PCS
DOD	90%
Cycle Life	≥6000 @ 25℃, 80% DOD
Maximum Charge & Discharge Current	200A
IP Rating	IP20
Installation Method	Floor-standing
Operating Temperature	0~55℃
Storage Temperature	-20~55℃
Humidity	≤80%
Product Dimensions	850530250mm
Package Dimensions	1000630470mm
Net Weight	125kg	130kg	135kg

Detailed Pictures

Powerful Drive Energy Saving LiFePO4 Wall-Mounted Home Energy Storage Battery

Company Profile Gallery

FAQ

Q Are you a factory or a trader?

A: We are a manufacturer integrating industry and trade.

Q Can I add my LOGO to the product?

A: We support on-demand customization, including LOGO customization, color customization, appearance size customization, etc.

Q What payment methods do you support?

A: We support T/T, Western Union, PayPal, cash, etc. The details can be negotiated.

Q What are your modes of transportation?

A: We usually choose the appropriate mode of transportation (sea, air, land) according to the conditions of the goods, or we can choose the mode of transportation according to your requirements.

Q How can I get an accurate quotation?

A: You can first send your specific demand information and product pictures, and we will customize a solution for you according to your needs and inform you of the specific price.
