Upgrade your home energy management with our Wall-Mounted Energy Storage System—a compact, high-performance LFP (Lithium Iron Phosphate) battery solution designed for residential and light commercial use.
Featuring a scalable capacity from 2.56kWh to 16.07kWh, this home battery backup system delivers exceptional reliability with an impressive 6000+ cycle life at 80% DOD.
The space-saving wall-mount design, combined with a built-in intelligent BMS (Battery Management System), ensures maximum safety and effortless installation.
Whether you're seeking solar energy storage, backup power, or off-grid independence, this premium-grade battery system offers the flexibility to connect up to 15 units in parallel, providing a truly customizable energy storage solution for your evolving needs.
| Model | SMP-BU004 | SMP-BU005 | SMP-BU006 |
|---|---|---|---|
| Battery pack specifications | |||
| Nominal Voltage | 51.2VDC | ||
| Voltage Range | 43.2~57.6VDC | ||
| Nominal Capacity | 280Ah | 300Ah | 320Ah |
| Rated Energy | 14.336kWh | 15.36kWh | 16.384kWh |
| Communication Protocol | CAN / RS485 / RS232 / WIFI / Bluetooth | ||
| Cell Self-discharge | <5% / month | ||
| Supported Parallel Quantity | 1~15 PCS | ||
| DOD | 90% | ||
| Cycle Life | ≥6000 @ 25℃, 80% DOD | ||
| Maximum Charge & Discharge Current | 200A | ||
| IP Rating | IP20 | ||
| Installation Method | Floor-standing | ||
| Operating Temperature | 0~55℃ | ||
| Storage Temperature | -20~55℃ | ||
| Humidity | ≤80% | ||
| Product Dimensions | 850*530*250mm | ||
| Package Dimensions | 1000*630*470mm | ||
| Net Weight | 125kg | 130kg | 135kg |
Q1Are you a factory or a trader?
A: We are a manufacturer integrating industry and trade. Welcome to visit our company.
Q2Can I add my LOGO to the product?
A: We support on-demand customization, including LOGO customization, color customization, appearance size customization, etc.
Q3What payment methods do you support?
A: We support T/T, Western Union, PayPal, cash, etc. The details can be negotiated.
Q4What are your modes of transportation?
A: We usually choose the appropriate mode of transportation (sea, air, land) according to the conditions of the goods, or we can choose the mode of transportation according to your requirements.
Q5How can I get an accurate quotation?
A: You can first send your specific demand information and product pictures, and we will customize a solution for you according to your needs and inform you of the specific price.
