| Parameter | Unit | Specifications | |
|---|---|---|---|
| Inverter Parameter | |||
| Rated Output Power | KW | 5.5 | 11 |
| Rated Output Voltage | VAC | 230 | |
| Input Voltage Range | VAC | (170-280Vac)±2% (90-280Vac)±2% | |
| Max PV Input Power | W | 6000 | 12000 |
| Max PV Input Voltage | Vdc | 500 | |
| MPPT Voltage Range | Vdc | 120-450 | |
| Max PV Charging Current | A | 22 | 22 |
| Battery Parameter | |||
| Battery Type | - | LiFePO4, 16S1P | |
| Battery Capacity Per Pack | AH | 100 | - |
| Battery Power | - | 5.12kWh * (2-4 Suggestion) | 5.12kWh * (4-8 Suggestion) |
| Rated Voltage | V | 51.2 | |
| Rated Output Current | A | 100 | |
| BMS Protective Current | A | 105 | |
| Charging Cut-off Voltage | V | 57.6 | |
| Charging Current | A | 50 | 100 |
| Maximum Charging Current Of the Mains | A | 60 | 120 |
| Peak Charging Current | A | 100 | 200 |
| Charging Mode | - | Constant Current/ Constant Voltage | |
| Discharge Cut-off Voltage | V | 42.4 | |
| Discharge Current | A | 100 | 200 |
| Maximum Discharge Current | A | 100 | 200 |
| Charging Temperature | ℃ | 0-65℃ (32-149℉) | |
| Discharge Temperature | ℃ | -20-65℃ (-4-149℉) | |
| Storage Temperature (>1 month) | ℃ | 0-35℃ | |
| Storage Temperature (≤1 month) | ℃ | -20-45℃ | |
| Ambient Humidity | - | 15-90% Relative Humidity (no condensation) | |
| Cycle Life | - | 6000 Cycles (25℃), 80% DoD @25℃ | |
